Motorola AP-650

物理参数

可用安装配置
AP650 (internal antenna): Ceiling-mount (to suspended ceiling T-bars, below tile); wall mount AP650 (external antenna): Ceiling-mount (above tile); wall-mount
外壳
金属、阻燃材料外壳
尺寸 (HxWxD)
AP650 (internal antenna): 9.5 in. L x 7.5 in. W x 1.7 in. H 241.3 cm L x 189.61 cm W x 43.6 cm HAP650 (external antenna): 8.5 in. L x 5.6 in. W x 1.5 in. H216.4 cm L x 141.0 cm W x 37.71 cm H
物理接口
2 ports (GE1, GE2) Auto-sensing 10/100/1000 Base-T Ethernet; 802.3af on GE1 LAN port
重量
AP650 (internal antenna): 2.0 lbs./.91 kgAP650 (external antenna): 2.5 lbs./1.14 kg
LED 指示器
2 LED indicators with multiple modes indicating 2.4GHz/5 GHz Activity, Power, Adoption and Errors

电源规格

集成式以太网供电支持
符合 IEEE 802.3af 标准
工作电流
270mA (typical)
工作电压
802.3af supply: 48 VDC @ 12.95W (typical), 36 VDC to 57 VDC (range)

无线规格

最大输出功率设置
24 dBm
支持的数据速率
802.11b/g: 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48, and 54Mbps802.11a: 6, 9, 12, 18, 24, 36, 48, and 54Mbps802.11n: MCS 0-15 up to 300Mbps
工作频段 - 欧盟
FCC EU 2.412 to 2.462 GHz 2.412 to 2.472 GHz 5.150 to 5.250 (UNII -1) 5.150 to 5.250 GHz5.725 to 5.825 (UNII -3) 5.150 to 5.350 GHz 5.725 to 5.850 (ISM) 5.470 to 5.725 GHz(Country Specific) Japan 2.412 to 2.484GHz 4.900 to 5.000 GHz 5.150 to 5.250 GHz
网络标准
802.11a, 802.11b, 802.11g, 802.11n
工作信道
5GHz: All channels from 4920 MHz to 5825 MHz2.4GHz: Chan 1-13 (2412-2472 MHz), Chan 14 (2484 MHz) Japan onlyActual operating frequencies depend on national regulatory limits
工作频段 - 欧盟
FCC EU 2.412 to 2.462 GHz 2.412 to 2.472 GHz 5.150 to 5.250 (UNII -1) 5.150 to 5.250 GHz5.725 to 5.825 (UNII -3) 5.150 to 5.350 GHz 5.725 to 5.850 (ISM) 5.470 to 5.725 GHz(Country Specific) Japan 2.412 to 2.484GHz 4.900 to 5.000 GHz 5.150 to 5.250 GHz
安全
Stateful Firewall, NAT, 802.1x, 802.11i, WPA2-CCMP (AES), WPA2-TKIP, WPA-TKIP, Triple-Methodology Rogue Detection with 24x7 dual-band Wireless IPS sensing, Secure guest access (HotSpot)
第2层和第3层
Layer 3 routing, 802.11-802.3 bridging, 802.1q VLAN tagging and trunking, Dyn DNS, DHCP server/client, PPPoE
无线媒介
Direct Sequence Spread Spectrum (DSSS) and Orthogonal Frequency Division Multiplexing(OFDM), and Spatial Multiplexing (MIMO)
管理
Adaptive Management by Centralized Switch, SSH, Telnet, SNMP v1/v2/v3, Auto-configuration with DHCP options, RFMS
QoS
802.11e, 802.1p, DiffServ, TOS

法规规定

EMC
EN 301 489-1, EN 301 489-17, IEC 60601-1-2, EN 55022, FCC 第 15 部分 B 级, ICES 003 B 级, EN 55024, EN 61000-3-2, EN 61000-3-3
电气安全
UL 60950, cUL, EU EN 60950, TUV and UL 2043 (external antenna)
人体暴露 EMF
EN 50385, FCC 第 2 部分、OET Bulletin 65, RSS-102 第 2 版
环境标准
EU RoHS 指令 2002/95/EEC
环境标准
EU RoHS 指令 2002/95/EEC

使用环境

静电释放
+/- 15 kV (Air), +/- 8 kV (contact)
工作高度
8, 000 ft./2438 m
工作湿度
5 to 95% RH (non condensing)
工作温度
32°F to 122° F/0°C to 50° C
储存高度
15, 000 ft./4572 m
储存温度
-40°F to 158° F/-40°C to 70° C
